Home » Products » QC12Y Shearing Machie » QC12Y SHEAR MACHINE



HPSW-Shears HPSW HPSW HPSW HPSW HPSW HPSW HPSW HPSW HPSW HPSW HPSW
  4mm-2500 6mm-2500  6mm-3200  6mm-4000 8mm-2500 8mm-3200 8mm-4000 10mm-3200 10mm-4000 13mm-3200 13mm-4000

Cutting Length (mm) 2500 2500 3200 4000 2500 3200 4000 3200 4000 3200 4000

Material Max (Mild Steel) 4 6 6 6 8 8 8 10 10 13 13

Shear Angle 1.30* 1.30* 1.30* 1.30* 1.30* 1.30* 1.30* 1.30* 1.30* 1.30* 1.30*

Throat Depth  150 150 150 150 150 150 150 150 150 150 150

Stroke of Backgauge (mm) 780 780 780 780 780 780 780 780 780 780 780

Height of Table 780 780 780 780 800 800 800 800 800 850 850

Main Motor  (kw) 4 7.5 7.5 7.5 11 11 11 15 15 18.5 18.5

NC Control E-21 E-21 E-21 E-21 E-21 E-21 E-21 E-21 E-21 E-21 E-21


Weight of Machine (kg) 33000 4000 5300 6800 6500 6500 7720 8500 9100 10000 11400

Dimensions (mm)  Length 3130 3130 3840 4800 3148 3840 4800 3900 4800 3925 4800
Dimensions (mm)  Depth 1500 1530 1675 1850 1750 1800 1950 1800 2000 1800 2000
Dimensions (mm)  Height 1580 1600 1620 1650 1760 1760 1750 1760 1800 1940 2050
