Home » Products » Band Saw » GB4230 Band Saw

Product Description for GB4230 column metal cut horizontal bandsaw



1 The cut-off time of the machine is 4 to5 times that of hack sawing machine

2 The saw kerfs is 2mm narrower than of hack sawing machine.

3 It saves the consumption of electricity from 50%-60% the hack sawing machine with the same work.

4 Hydraulic feeding, step less speed regulation.

5 Hydraulic claming, automatic stopping.

6 Simple and convenient operation and maintenance







         Type

Specification

Unit

GB4230

GB4235

GB4240

GB4250

Cutting capacity

mm

Round: Φ300

Square:280*400

Round: Φ350

Square:350*400

Round: Φ400

Square:400*450

Round: Φ500

Square:500x550

Blade Speed

m/min

27,40,50,70

30,45,55,80

20,30,37,53

20,30,38,56

Blade size

mm

1.1*34*4000

1.1*34*4540

1.3*41*4740

1.3*41*5450

Main motor power

kw

3

3

3

4

Hydraulic

kw

0.37

0.37

0.75

0.75

Coolant pump

kw

0.04

0.04

0.085

0.085

Machine Size

(L*W*H)

mm

2060*950*1340

2230*1000*1500

2400*1050*1600

2700*1100*1850

Weight

kg

1100

1200

1400

1500
