Home » Products » SPRIAL DUCT FORMING MACHINE » JX-1500D SPRIAL DUCT FORMING MACHINE

Diameter Range

200-1500mm

Maximum Tube Length

Unlimited mm

Thickness of Strip

0.4-2.0mm

Width of Strip

137-mm

Strip Speed

1-36m/min

Suitable Material

Aluminum, Stainless steel, Galvanized steel,etc

Dimension (L x W x H)

2650mm*1550mm*2000mm

Weight

2260kg

Main Motor Power

11kW

Cutting Motor Power

5.5kW

Air Pressure

0.5-2.0Mpa
